I finally managed to make it work … 🙂 So this time we are trying to establish multichannel between Debian Linux with Samba 4.9.5-Debian and Windows server 2019 (that preferres SMB 3.1.1 dialect). Each of VMs on separate Hyper-V hosts has 4 virtual network adapters connected. I entered the hostnames of VMs in hosts files both – on Windows and Linux as I am not running any DNS server in the test network.
So I added 4 entries on each machine. On Debian I have created a simple smb.conf example file to make it work:
workgroup = WORKGROUP
interfaces = eth0, eth1, eth2, eth3
bind interfaces only = Yes
vfs objects = recycle aio_pthread
aio read size = 1
aio write size = 1
strict locking = No
use sendfile = no
server multi channel support = yes
server string = samba server
security = USER
encrypt passwords = yes
smb passwd file = /etc/samba/smbpasswd
guest ok = yes
comment = Storage
path = /var/samba
writeable = yes
public = no
As you can see in video by using Linux command in terminal: smbstatus I am getting similar information as running get-smbmultichannel Powershell cmdlet on Windows. I can clearly see how servers are connected between them by using SMB protocol.
As you can see in video Windows machine, from which I am copying data to Linux utilizes all four network adapters but we are getting only 2 gigabit throughput. On Linux side there are only two NICs utilized. I was not able to make it work by using all four adapters (like machines were utilizing in previous part in Windows VM to Windows VM scenario). Well I just wanted to demonstrate that concept works also in mixed environment with Windows and Linux.
We are pushing it forward – in previous example (part 3) we made virtual switch just by simply using Hyper-V Manager (or Powershell) but with no extra configuration – the result was that when copying from server to server we got only 1 gigabit throughput.
Now, we are trying to upgrade the scenario by using Powershell (you can only do this by using Powershell or by using System Center Virtual Machine Manager (that below also uses Powershell :)) – we are going to create Virtual Switch but then we are going to assign more than just one virtual network card to host operating system (our Hyper-V host):
We simply create a virtual switch, that does not have in previous part mentioned checkbox “Allow management operating system to share this network adapter” checked so, no Virtual Network card is created – !Warning! If you run only this cmdlet you will cut yourself out of your Hyper-V host – so it is better to prepare also the second part and run it all together so we will continue by using cmdlet Add-VMNetworkAdapter:
As I told you at the beginning of this series I am a big fan of Hyper-V – I have been implementing it since 2008 (when nobody believed this would ever become a serious virtualization platform :)). So in Windows server 2012 / 2012 R2 the most common way of setting up your Hyper-V networking was to just team your NICs by using Windows provided tool and then just to create a VMSwitch on top of it – by using Hyper-V manager or Powershell and by using the checkbox Allow management operating system to share this network adapter. After this process you ended up with a new virtual NIC called for example vEthernet (Team01).
Like in previous scenario (part 2) we have 1 gigabit speed when copying files from server to server. And yes, if there was a third server we would probably start using next NIC so we would have 2 gigabit traffic from server 1 – 1 gigabit to server 2 and 1 gigabit to server 2 – but still just a gigabit to each of them.
In this video you can see that we are upgrading previous scenario (teamed NICs) by enabling Hyper-V Virtual Switch (External type) using Hyper-V Manager – you could also do that by using Powershell following the documentation.
As you probably saw in my previous post – if you leave your cards just as they are – connected to switch SMB multichannel kicks in when you start to copy something to another machine that also has multiple NICs … But what happens in server to server scenario when you team your interfaces by using teaming that is included in windows – the one that you can configure by using server manager (and of course by using PS).
Well when you team your interfaces you get a new interface (you will see an interface with Microsoft Network Adapter Multiplexor).
Well in server to server scenario it means that you have only one NIC which reduces the speed of your copying to a speed of a single card in NIC.
As you can see also in Powershell by using Get-SmbMultichannelConnection cmdlet we have just one session.
Yes, if there was a third server we would probably start using next NIC so we would have 2 gigabit traffic from server 1 – 1 gigabit to server 2 and 1 gigabit to server 2 – but still just a gigabit to each of them.
Just a quick remark … You can create teaming interface by using Server manager or you can use Powershell – more information about creating teamed interface can be found here.
I am a big fan of SMB 3.x multi-channel feature that Microsoft implemented for the first time in Windows server 2012. As I am also a big fan of Hyper-V and I want my hosts to have the ability to copy files between them (ISOs, VHDXs …) as fast as possible I wanted to create this short series of articles about multi-channel feature. I was really happy when I saw Mr. Linus Sebastian posted a video Quadruple Your Network Speed for $100 with SMB 3.0 Multichannel!so I decided to create a small series of videos to also see what advantages of using it in a production environment are and why.
For this test I used 2xDell R730xd with 2 CPUs (Xeon E5-2620) and with Dell Intel I350 Quad-Port Gigabit Ethernet and MikroTik switch CRS226-24G-2S+.
So in this first part I would like to show, how SMB 3.x multichannel (I am putting that x there as SMB versions are changing (table at point 4) in each release of Windows server (and client too!) works.
In this demo I will be using Windows server 2019 which uses SMB dialect 3.1.1. You can check the dialect that your servers / clients are using by typing following cmdlet in Powershell: Get-SmbConnection
In the following video you can see the first example – two servers connected with 4 NICs each to the switch – without any extra configuration (there are no IP addresses configured) but you can see that when we copy files from server 1 to server 2 we utilise all 4 NICs on server 1 and all 4 NICs on server 2 – it can be clearly seen also on switch. To get information how your server utilizes SMB 3.x multichannel you can use Powershell cmdlet: Get-SmbMultichannelConnection
